Heavy duty fire-rated hinged landing doors are complimented with a choice of drop bar or lattice gate car protection. This model is also available with an option of double-hinged landing doors.

Two special Pallet Lifts have been developed specifically to carry a single Europallet (dimensions 800mm x 1200mm) and a single UK style pallet (dimensions 1000mm x 1200mm). Both lifts have a maximum load of 300kg.

• Download the BKG Service Lift brochure

B.K.G Type:		100. 39/9	300 .30/11	300 .30/12	300 .30/13
Rated Load (KG)		100	250	100	250
Speed (M.P.S.)		0.30	0.30	0.30	0.30
Traction Drive-Rope Suspended-No of Ropes		3	5	3	5
Car Width*	min	400	400	600	600
	max	1000	1000	1000	1000
Car Depth*	min	600	800	700	800
	max	1000	1000	1000	1000
Car Height*		1200	1200	1200	1200*
Doors at Service Level		-	-	-	-
Doors at Floor Level		yes	yes	yes	yes
Through Entry Loading		yes	yes	-	-
Adjacent Entry Loading		-	-	yes	yes
Lift Shaft Width = Car Width +		400	400	450	450
Lift Shaft Depth = Car Depth +		120	120	450	450
Headroom = Car or Door Height + Serving Height +		1400	1400	1400	1400
Pit Depth		350	350	350	350
Car Door Type		**	**	**	**
Landing Door Type		Hinged door
Two Tier Car		-	-	-	-
