Service lifts for hotels and restaurants

Wherever food needs to be transported between floors, the BKG range of dumbwaiters offers the ideal answer.

Service lifts for hospitality

To satisfy hygiene demands, stainless steel shelves and floors are supplied as standard. Other stainless steel surface finishes are available as an option. A special seamless hygienic car is available as an option for more rigorous requirements. Car protection is an important consideration when moving food as are the optional heated compartments.

Automatic "hands free" doors are available as an option on this range of lifts. A bottom drive variant is available for applications where low headroom is a problem. A special two tier Combination lift is available - effectively two lifts in one - so that different types of goods can be moved in the same unit.

For administration applications, two document lift models with 5kg and 20kg capacities are also available. Call us on 0800 612 1055 for more information about our range of service lifts and dumb waiters for hospitality.

B.K.G Type: 50. 45/0 100. 45/0 50. 45/7 100. 45/1 100. 30/2 300. 30/2 300. 30/14 300. 30/15 100. 45/8 100. 45/6
Rated Load (KG) 50 100 50 100 100 100 250 250 100 100
Speed (M.P.S.) 0.45 0.45 0.45 0.45 0.45 0.3 0.3 0.3 0.45 0.45
Traction Drive-Rope Suspended-No of Ropes 3 3 3 3 3 3 5 5 - -
Direct Drive-Chain Suspended-No of Chains - - - - - - - - 2 2
Car Width* min 400 400 400 400 400 400 400 400 400 400
max 800 600 800 1000 1000 1000 1000 1000 800 900
Car Depth* min 400 400 400 500 600 700 800 800 500 500
max 800 600 800 1000 1000 1000 1000 1000 800 1000
Car Height Max 800 800 800 800 1200 1200 1200 1200 800 1200
Type of Landing Doors Vertical Bi-Parting Doors
Doors at Service Level yes yes yes yes yes - yes - yes yes
Doors at Floor Level - - - - - yes - yes - -
Through Entry Loading yes yes - - yes yes yes yes - -
Adjacent Entry Loading - - yes yes - - - - yes yes
Lift Shaft Width = Car Width + 320 320 320 320 320 320 320 320 320 320
Lift Shaft Depth = Car Depth + 180 180 240 240 180 180 180 180 180 180
Headroom = Car or Door Height + Serving Height + 1190 1190 1345 1345 **1390 1390 1390 1390 1345 1345
Pit Depth = Door Height + 2 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
